THE DEVELOPMENT THE AUTOMATIC ACCIDENT ALERT WITH VEHICLE TRACKING SYSTEM USING GSM

Saturday 25 August 2012

week 4 (FYP 1)

MICRO-CONTROLLER

          Micro-controller is a on-chip computer or single chip computer. This small device is used to control event, processes and objects. Another term to describe micro-controller is embedded controller because the microcontroller and its support circuits are often built into, or embedded in, devices they control. Any device that measures, stores, controls, calculates and displays information is a candidate for putting micro-controller inside. Micro-controller contains memory, I/O interfaces in addition to the C.P.U. Because the amount of memory and interfaces is limited so micro-controllers are used for smaller system. In this project, micro-controller 8051 is used.

Block Diagram of MICROCONTROLLER 8051



PIN DISCRIPTION

VCC                   -     Supply voltage
GND                   -     Ground
PORT 1              -      Port 1 is an 8 – bit bi directional I/O port. Port pins p1.2 to
                                   P1.7 provides internal pull - ups. P1.0 and P1.1 require
                                   external pull- ups. P1.0 and P1.1 also serves as positive input
                                   and negative input.
PORT 3              -      Port 3 pins P3.0 to P3.5, P3.7 are seven bi directional I/O
                                   pins with internal pull-ups.P3.6 is hard wired as an input to
                                   output of the on chip comparator and is not accessible with
                                   general purpose I/O pin.

Port pin
Alternate function
P3.0
RXD (SERIAL INPUT PORT)
P3.1
TXD (SERIAL OUTPUT PORT)
P3.2
INT0(INTERNAL INTERRUPT O
P3.3
INT 1 (EXTERNAL INTURREPT 1)
P3.4
T0 (TIMER 0)
P3.5
T1 (TIMER 1)
   TABLE 2.2 PIN FUNCTIONS OF MICROCONTROLLER 8051

Port 3 also receives some control signals for flash programming and verification.
RST         -    Reset input
XTAL1    -    Input to the inverting oscillator amplifier and input to the internal
                     Clock operating circuit.
XTAL2    -    Output from inverting oscillator amplifier.
